APC by Schneider Electric NetShelter PDU

  • Part: 1036782
  • Model: AP8659
$2,429.90

Availability

In Stock

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com.au
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • NetShelter
    • Product Series
    • Switched Metered
    • Product Type
    • PDU

APC Metered by Outlet with Switching Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and individual outlet power metering. Remote outlet level controls allow power on/off functionality for power recycling to reboot locked-up equipment and to avoid unauthorized use of individual outlets. Power sequencing delays allow users to define the order in which to power up or down attached equipment. Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding. Current metering provides real-time remote monitoring of connected loads. Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles. User-defined alarms warn of potential circuit overloads before critical IT failures occur. Users can access, configure, and control Switched rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager.

  • Warranty
    • Limited Warranty
    • 2 Year

  • Technical Information
    • Plug/Connector Type
    • IEC 60320 C20
    • Receptacle Type
    • IEC 60320 C19
    • IEC 60320 C13
    • Receptacle Detail
    • 3 x IEC 60320 C19
    • 21 x IEC 60320 C13
  • Power Description
    • Input Voltage
    • 200 V
    • 208 V
    • 230 V
    • Output Voltage
    • 100 V AC
    • 200 V AC
    • 208 V AC
    • 230 V AC
  • Management
    • Management
    • Protocols:

      • SNMP
      • Telnet
  • Physical Characteristics
    • Mount Type
    • Rack-mountable
    • Rack Height
    • 0U
    • Height
    • 1829 mm
    • Width
    • 56 mm
    • Depth
    • 51 mm
    • Weight (Approximate)
    • 6.09 kg
  • Miscellaneous
    • Package Contents
      • Metered-by-Outlet Rack PDU
      • CAN Port Terminator
      • Installation Guide
      • Rack Mounting Brackets
      • Safety Guide
      • Serial Configuration Cable
    • Environmentally Friendly
    • Yes
    • Green Premium
    • Yes
    • Optimized Energy Efficiency
    • Yes
    • Product Take Back Program
    • Yes
    • REACH free of SVHC
    • No
    • Mercury Free
    • Yes
    • Lead Free
    • Yes
    • RoHS Exemption Information
    • https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP8659_ROHS_DECLARATION&p_FileName=AP8659KIT_ROHS_DECLARATION_US.pdf
    • REACH Declaration URL
    • https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=323194454&lang=en-us
    • EU RoHS Declaration URL
    • https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=323194454&lang=en-us
    • Environmental Profile Availability
    • https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612035_EN
    • End of Life Manual Availability
    • https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512009_V1
    • California Proposition 65 Warning
    • WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
    • WEEE Statement
    • The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
