Outstanding Value for business at any sizes
Engineered for the specific demands of small business, ASUS ExpertCenter D5 SFF is a desktop with AI-driven Microsoft Copilot that delivers powerful, trustworthy and expandable performance. Its modern, ultra-compact, and flexible design caters to diverse workspaces and usage scenarios - and allows businesses to take advantage of ASUS-exclusive small-business support services to minimize both downtime and total cost of ownership and maximize the value of your investment.
Secure manageability
ExpertCenter D5 SFF prioritizes security through TPM 2.0, providing advanced protection with two options: a software-based firmware TPM solution running on the CPU; or discrete TPM (dTPM), a dedicated chip offering an additional layer of defense against sophisticated threats.
Efficient expandability
The perfect balance of performance and size with remarkable expandability that provides space for essential hardware to support diverse productivity needs.
- General Information
- Manufacturer
- ASUS Computer International
- Manufacturer Website Address
- http://www.asus.com/au
- Brand Name
- Asus
- Product Line
- ExpertCenter D5
- Product Series
- D500
- Product Type
- Desktop Computer
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
3Y OnSite Service
- Technical Information
- AI-powered
- Yes
- Processor
- Processor Manufacturer
- Intel
- Processor Type
- Core i7
- Processor Generation
- 14th Gen
- Processor Model
- i7-14700
- Processor Core
- Icosa-core (20 Core)
- Processor Speed
- 2.10 GHz
- Maximum Turbo Speed
- 5.30 GHz
- Processor Threads
- 28
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- B760
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR5 SDRAM
- Memory Configuration
- 2 x 8GB
- Number of Occupied Memory Slots
- 2
- Storage
- Drive Type
- SSD
- Total Solid State Drive Capacity
- 512 GB
- Solid State Drive Interface
- PCI Express NVMe 4.0
- SSD Form Factor
- M.2
- Display & Graphics
- Graphics Controller Manufacturer
- Intel
- Graphics Controller Model
- UHD Graphics 770
- Graphics Memory Technology
- DDR5 SDRAM
- Graphics Memory Accessibility
- Shared
- Network & Communication
- LAN Manufacturer
- Intel
- LAN Model
- WGI219V
- Ethernet Technology
- Gigabit Ethernet
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11ax
- Bluetooth
- Yes
- Built-in Devices
- Sound System
- 7.1 Surround Sound
- Interfaces/Ports
- HDMI (Rear)
- Yes
- Total Number of USB Ports
- 8
- Number of USB 2.0 Ports (Front)
- 2
- Number of USB 2.0 Ports (Rear)
- 2
- Number of USB 3.2 Gen 1 Ports
- 2
- Number of USB 3.2 Gen 2 Ports
- 2
- Number Of Ethernet Ports
- 1
- VGA (Rear)
- Yes
- Optional Ports
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 x SD card reader (optional)
- 1 x Serial port (optional)
- Operating System
- Operating System Platform
- Windows
- Operating System
- Windows 11 Pro
- Power Description
- Maximum Power Supply Wattage
- 330 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Small Form Factor
- Height
- 309 mm
- Width
- 93 mm
- Depth
- 296 mm
- Weight (Approximate)
- 6 kg
- Miscellaneous
- Package Contents
- ExpertCenter D5 D501SERES-714700020X Desktop Computer
- Wired Optical Mouse
- Wired Keyboard
- Features
- Security Slot
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
- Energy Efficiency Certification
- ENERGY STAR 8.0
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
