- General Information
- Manufacturer
- Samsung
- Manufacturer Website Address
- http://www.samsung.com/au
- Brand Name
- Samsung
- Product Line
- SyncMaster
- Product Series
- UX
- Marketing Information
RS232C In-Out
RS232C, a standard of serial communication, is used for the communication between PC and displays. A Multiple Display Control (MDC) allows various displays to be easily and simultaneously operated by a PC, which is possible with the RS232C function.
4 Anti-Image Retention Mode
Four types of anti-image retention can be set to be activated automatically throughout the day, contributing to longer panel life and greater reliability.
- Product Type
- Digital Signage Display
- Technical Information
- Features
- Picture in Picture
- Video Wall
- Processor & Chipset
- Processor Type
- Athlon X2
- Processor Model
- 4450e
- Processor Speed
- 2.30 GHz
- Memory
- Standard Memory
- 1 GB
- Memory Technology
- DDR2 SDRAM
- Storage
- Total Hard Drive Capacity
- 40 GB
- Hard Drive Interface
- Serial ATA
- Display & Graphics
- Viewable Screen Size
- 46"
- Display Screen Type
- LCD
- Display Resolution
- 1920 x 1080
- Graphics Modes
- WUXGA
- Response Time
- 8 ms
- Aspect Ratio
- 16:9
- Horizontal Viewing Angle
- 178°
- Vertical Viewing Angle
- 178°
- Audio
- Number of Speakers
- 2
- Speakers
- Yes
- RMS Output Power
- 20 W
- Video
- Scan Format
- 1080p
- Standard Refresh Rate
- 85 Hz
- Native Contrast Ratio
- 4,000:1
- Brightness
- 700 cd/m²
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- USB
- Yes
- USB Standard
- USB 2.0
- DVI
- Yes
- VGA
- Yes
- HDMI
- Yes
- Component Video
- Yes
- Composite Video
- Yes
- Network (RJ-45)
- Yes
- Software
- Operating System
- Windows XP Embedded
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Physical Characteristics
- VESA Mount Compatible
- Yes
- Height
- 60.3 cm
- Width
- 105 cm
- Depth
- 12 cm
- Weight (Approximate)
- 27.70 kg
- Miscellaneous
- Additional Information
- Pixel Pitch: 0.530 mm
- Audio: Realtek ALC262
- Power Consumption: 320 W Typical
- Power Consumption Standby: Under 1 W
- Certifications & Standards
- TUV GS
- CE
- ISO 13406 / 2
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
